Precise Die Cut Offset Printing Polycarbonate Profile Sheet For PC Card Body Production
Product Details:
| Place of Origin: | China |
| Brand Name: | MK |
| Model Number: | MUO-PC |
Payment & Shipping Terms:
| Minimum Order Quantity: | 30000 sheets or 2 tons |
|---|---|
| Price: | Negotiable |
| Packaging Details: | By reel or 500 sheets per bag, 4 bags per paper carton and with standard export carton, and the cartons are piled up and firmly fixed on solid plywood pallets |
| Delivery Time: | 10-15 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10 million square meters or 3 million tons per month |
|
Detail Information |
|||
| Color: | Transparent Or Clear | Thickness Range: | 0.04mm , 0.05mm，0.06mm，0.08mm，0.10mm |
|---|---|---|---|
| Normal Size: | By Sheet Or By Reel, A4, A3 Or As Per Customer Requirements | Surface: | With No Glue Coating On Both Sides |
| Dielectric Strength: | 1700V/mil | Vicat Softening Point: | 148℃ |
| Tear Strength: | >65g/mil | Average Water Absorption: | 0.35% |
| High Light: | precise die cut pc plastic sheet,offset printing pc plastic sheet,offset printing polycarbonate pc sheet |
||
Product Description
Normal PC Films Without Coating Laminated With PC Plastic Sheet for PC Card Body Production
Production Specification
| 1. Normal PC Films Without Coating Laminated With PC Plastic Sheet Introduction |
Normal PC Films Without Coating Laminated With PC Plastic Sheet is specially produced for PC card body lamination with printed sheets. It has such good features like strong lamination adhesion, excellent tensile strength, wear resistance and high temperature resistance. It is widely used in such cards as anti-fake IC cards, driving license card, transportation card and passport etc.
Normal PC Films Without Coating Laminated With PC Plastic Sheet has many special characteristics that other engineering plastics don’t contain, due to the flexible carbonate group and the rigid benzene ring in its molecular structure. Therefore it’s widely used. Due to the specialty in its structure, PC has a range of unique advaes such as excellent light transmittance, relatively high glass transition temperature, desirable chemical modification, easy for physical modification, excellent impact toughness, creep resistance, electrical in insulation and weathering resistance.
PC overaly and sheets that made from polycarbonate have a wide range of temperature (-30~120℃), dimensional stability, excellent comprehensive properties and easy to process, therefore they are very widely used.
PC Plastic cards process in general :
1. Print directly to the surface of sheets
2. Hot press laminate with PC overlay films when the ink dries.
3. Punch out cards from the fused materials.
4. Other art-works, such as embossing, hot stamping, hole punching, screen printing etc.
5. Finished cards.
| 2. Normal PC Films Without Coating Laminated With PC Plastic Sheet Specification |
Product details :
Normal PC Films Without Coating Laminated With PC Plastic Sheet which is for PC card making ,this material has under mentioned advaes :
1. Excellent strength and wear-resisting.
2. High temperature and low temperate resistance.
3. Perfect application for anti-fake IC cards, driving license card, transportation card and passport etc..
4. Environment-friendly material.
5. Longer service life.
Parameters :
1. Size: in reel or in sheet as 210*297mm ( A4 ) , 310*480mm ( A3 ) or as per customer requirements
2. Normal thickness in mm: 0.04,0.05,0.06,0.08,0.10
3. Color : Transparent or without coating on surface.
4. Package method : in reel ,or 500 sheets per bag, 4 bags per carton or customized, and the cartons are piled up and firmly fixed on solid plywood pallets
5. Storage condition : Sealed, moisture-proof, room temperature under 40℃ , Keep it horizontally, avoid heavy pressing and direct sunlight .
6. Laser engraving performance: cannot be laser engraved
| Product name | Normal PC Films Without Coating Laminated With PC Plastic Sheet for PC Card Body Production |
| Model | MUO-PC |
| Color | Transparent or clear |
| Thickness Range | 0.04- 0.1 mm |
| Vicat point ℃ | 148 |
| Tensile strength | 165 Mpa |
| Tear strength | >65 |
| Density | 1.23g/cm³ |
| Thermal shrinkage | ＜0.5% |
| Roughness value | Ra0.58-3.2 |
| Glue coated | Without coating on both sides |
| Packing | PE Film inside + Carton box +Pallet |
| Advae |
Excellent strength and abrasion resistance, high and low temperature resistance; suitable for card body performance and anti-counterfeiting technology requirements, such as id card, driving license, e-passport, etc |
Normal PC Films Without Coating Laminated With PC Plastic Sheet is known as the new reliable material for PC card body production. It has such features as high vicat point and cannot be used for laser engraving. The PC sheet is perfect for making ID card, E-Passport etc.
Features as below:
Secure layered construction
Polycarbonate cards are made of layers of polycarbonate films, laminated into a single solid layer. Unlike other card materials, lamination can be carried out without the use of an adhesive. The films cannot be subsequently separated without destroying the card enhancing protection against tampering and fraud. Chips and antennas can be securely embedded in the layered films of a polycarbonate card.
Long-term performance
Polycarbonate overlay also offer excellent mechanical and thermal properties. They are resistant to heat up to 145°C and do not warp after extended exposure to high temperatures. Polycarbonate retains its stiffness even at low temperatures.
Polycarbonate is used to make CDs, bulletproof glass, water bottles and, increasingly, cards and secure passport laminates. Stronger and more expensive than PVC, its durability makes polycarbonate an ideal material for cards intended for a service life of ten years or more, such as national ID, passports and driving licenses. When finally incinerated for disposal, polycarbonate mainly produces water and carbon dioxide.
Personalization
Polycarbonate cards can benefit from the high-cost but virtually tamper-proof personalization technique of laser engraving.
| Feature | Testing method | Unit | Testing value |
| Physics | |||
| Specific gravity | ASTM D792 | G/cm³ | 1.23 |
| Average water absorption | ASTM D570 | % | 0.35 |
| Mechanical | |||
| Tensile strength | ASTM D882 | Psi | 9,800 |
| ISO R1184-1987 | Mpa | 165 | |
| Ultimate elongation | ASTM D882 | % | >155 |
| Impact strength | JIS-k6745 | In-ibs | 150 |
| Tear strength | ASTM D1922 | G/mil | >65 |
| Temperature resistance | |||
| Vicat softening point | ASTM D1525 | ℃ | 148 |
| Thermal shrinkage | D1204 | % | <0.5 |
| Electrical | |||
| Dielectric strength | ASTM D149 | V/mil | 1700 |
| Volume Insulation | ASTM D257 | Ohm.m | 10 16 |
| Surface Insulation | ASTM D257 | Ohm | 10 15 |
| Roughness value | |||
| Medium sand | um | Ra3.05~3.2 | |
| Fine sand | um | Ral.5~2.1 | |
| Matte | um | Ra0.58 | |
| Feature | unit | limit | |
| Thickness tolerance | % | >0.5±0.006mm | |
| ≤0.5 ±0.004mm | |||
| 3. Application of Normal PC Films Without Coating Laminated With PC Plastic Sheet |
It is widely used in such cards as anti-fake IC cards, driving license card, transportation card and passport etc.
| 4. Packing of Normal PC Films Without Coating Laminated With PC Plastic Sheet |
In standard export carton and are packed on plywood pallet
