Strong Adhesion Level PVC Coated Overlay

Strong Adhesion Level PVC Coated Overlay

Product Details:

Place of Origin: China
Brand Name: MK
Model Number: MCO-W

Payment & Shipping Terms:

Minimum Order Quantity: 20000 - 30000 sheets
Price: Negotiable
Packaging Details: 50 or 100 sheets per bag, 10 bags per paper carton, and the cartons are piled up and firmly fixed on solid plywood pallets.
Delivery Time: 10-15 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10 million square meters per month
Get Best Price Contact Now

Detail Information

Peel Strength (90°, 300mm/min): ≥ 6.0 N/cm Aging Time (65℃ Temp./95% Humidity ): >200 Hours
Vicat Softening Point: 72±2 ℃ Heating Shrinkage Ratio: ≤10 %
Normal Thickness In Mm: 0.04,0.05,0.06,0.08,0.10 Specific Density: 1.26 ±0.04 G / Cm3
High Light:

pvc overlay film

,

film frame overlay

Product Description

Laminating Material - PVC Coated Overlay With No Color Change And Deformation



We also call the PVC coated overlay  as PVC coating film for card body lamination, Coated film for card production, glue coated film for card, glue coating overlay for plastic card, card plastic material, card body plastic material





PVC Coated Overlay MCO-W ( strong adhesion level )



1. PVC Strong Coated Overlay Film Introduction



PVC Coated Overlay MCO-W model is suitable for laminating with most PVC sheets printed by various printers . It features high adhesion , no color change and deformation .
It is applicable to almost all sheets printed by various ink . It features excellent peeling strength and long aging time .



PVC Strong Coated Overlay Film with Strong initial viscous force , slow decline , yellowing resistance ,

deformating resistance after laminating.The surface is smooth , and easy to use. Mainly used for protective

film of bank card , social security card , IC card , RF card and other card with higher requirements.



Technical Parameters:



 Item  Parameters
 Vicat softening point     72±2 ℃
 Heating Shrinkage ratio     ≤ 10 %
 Tensile Strength  ≥ 40 MPa
 Normal thickness in mm  0.04 , 0.05,0.06,0.08,0.10
 Peel Strength (90°, 300mm/min)  ≥ 6.0 N/cm
 Aging time (65℃ temp./95% humidity ) >200 hours
 Suitable ink  offset and silk screen printing UV ink, Pigment and dye ink for inkjet printing as well as digital   printing ink


Strong Adhesion Level PVC Coated Overlay 0



Strong Adhesion Level PVC Coated Overlay 1



2. PVC Strong Coated Overlay Film Specification
  Item Unit Value
  Density g/cm3 1.26 ±0.04
  Tensile Strength Horizontal MPa ≥35
  Vertical ≥40
  Vicat 5kg 72±2

Customer design can be accept.



3. Applications of PVC Strong Coated Overlay Film



Strong Adhesion Level PVC Coated Overlay 2



4. Packing of PVC Strong Coated Overlay Film



Strong Adhesion Level PVC Coated Overlay 3
