A4 3mm White Laminated Pad Woolen Felt Cushion Material For RFID Card Lamination

Product Description

Woolen Surface Felt Cushion White Laminated Pad For Plastic Card Laminating Process

Production Specification

Woolen Surface Felt Cushion White Laminated Pad is designed for the lamination process for various plastic cards including bank card , credit card , and royalty card . It works with lamination steel plate in the plastic card lamination process .

One sheet laminating pad is used both at the bottom and top while lamination to ensure balance temperature and pressure. High temperature resistances, high pressure resistance, heat quickly and evenly, improve the card quality. Laminated pad has two types, silicone wool pad and a rubber cushion, etc.

The structure of white silicon cushion pads is white heatproof silicon rubber layers on the surfaces with glass filer in the middle .

Woolen Surface Felt Cushion White Laminated Pad is suitable for manufacturing kinds of ISO standard cards, ID cards and smart cards . Raw materials are all for anti-high temperature and anti-high pressure. Meeting the requirements of laminating process, as the professional card consumables, they have been widely using for improving the production efficiency and saving energy because of the feature of thermal conductive fast and uniform . Have excellent bibulous performance, can effectively eliminate the risks of bubbles and watermarks on card surface , greatly improved the qualification rate of products, and with good cushioning properties , they can avoid the scratches linked to the hard touching between the heating plate and the trays , benefited to the long using life of above both.

Key Features:

1. It is heatproof with great durability, which can well meet the technological requirements in plastic card lamination .

2. It can transfer heat quickly and evenly , which can improve production efficiency and energy conservation .

3. It has good performance of high temperature resistance and excellent elastic resilience .

4. It has good cushioning performance to avoid the damage and scratching resulting from direct contacting between laminator template and lamination steel plates , which can extend the service life of both lamination steel plates and template .

Detailed Product Description

(1) Woolen Surface Felt Cushion
(2) High tensile strength and tearing strength, heat resistant up to 250
(3) Long service life
(4)  Product Application: It is used for hot-press , widely used for card laminating or furniture , wooden doors of the pressure paste .

(5) Product specification: 1) thickness: 3.5 -4.5 mm 2) maximum width: 3800mm with no joint 3) any length 4) color: white

Product Parameter :

1. Heatproof performance: 200℃

2. Tensile strength: 80 N/mm

3. Adhesion: 80 N/mm

4. Hardness SHORE A: 55±5

5. Thickness: 3mm

6. Length and width: A4, A3 or custom-made size (size tolerance: ±1mm)

The technical index:

It is used for hot-press , widely used for card laminating or furniture , wooden doors of the pressure paste .

In standard export carton

In standard export plywood case
