High Adhesion 40Mpa 0.04mm RF Card PVC Overlay Sheet
Product Details:
| Place of Origin: | China |
| Brand Name: | MK |
| Model Number: | MCO-W |
Payment & Shipping Terms:
| Minimum Order Quantity: | 30000 sheets or 2 tons |
|---|---|
| Price: | Negotiable |
| Packaging Details: | by reel or 500 sheets per bag/4-8 bags per paper carton, or as per customer requirements. All the cartons are firmly piled up and fixed on the solid plywood pallet. |
| Delivery Time: | 10-15 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 20 million square meters or 5 million tons per month |
|
Detail Information |
|||
| Normal Thickness Range: | 0.04mm-0.1mm | Common Size: | By Roll Or By Sheet :A4, A3 Or Customized |
|---|---|---|---|
| Aging Time: | ＞200 Hours (65℃ Temp./95% Humidity ) | Coating: | Glue Coating On One Side Of The Overlay Sheet |
| Suitable Ink: | Offset And Silk Screen Printing UV Ink, Pigment And Dye Ink For Inkjet Printing As Well As Digital Printing Ink | Application: | For Smart Card Body Material Production |
| High Light: | 40Mpa PVC Overlay Sheet,0.04mm PVC Overlay Sheet,high adhesion PVC Overlay Sheet |
||
Product Description
40 Mpa PVC Overlay Sheet Strong Adhesion Level PVC Coated Film For PVC Card Sheets Laminating
1. Introduction of 40 Mpa PVC Overlay Sheet Strong Adhesion Level PVC Coated Film For PVC Card Sheets Laminating
PVC Coated Overlay MCO-W model is suitable for laminating with most PVC sheets printed by various printers. It features high adhesion, no color change and deformation.
It is applicable to almost all sheets printed by various ink. It features excellent peeling strength and long aging time.
PVC Strong Coated Overlay Film with Strong initial viscous force , slow decline , yellowing resistance ,
deformating resistance after laminating.The surface is smooth , and easy to use. Mainly used for protective
film of bank card , social security card , IC card , RF card and other card with higher requirements.
2. Specification of 40 Mpa PVC Overlay Sheet Strong Adhesion Level PVC Coated Film For PVC Card Sheets Laminating
Overlay films
Overlay films ensure high clarity and superior graphic visibility for your graphics. Our overlay films deliver exceptional performance: gauge control, color consistency (before and after lamination), and bond strength that exceeds ISO standards.
Coated films
Adhesion to UV, oxidative, digital or silk screen inks
Various adhesive coatings available
Themoprintable and laser engravable films
various vicat (temperature resistant) films
| Item | Parameters |
| Vicat softening point | 72±2 ℃ |
| Heating Shrinkage ratio | ≤10 % |
| Tensile Strength | ≥40 MPa |
| Normal thickness in mm | 0.04,0.05,0.06,0.08,0.10 |
| Peel Strength (90°, 300mm/min) | ≥6.0 N/cm |
| Aging time (65℃ temp./95% humidity ) | ＞200 hours |
| Suitable ink | offset and silk screen printing UV ink, Pigment and dye ink for inkjet printing as well as digital printing ink |
PVC Coated Overlay - Parameters:
1). Size: in reel or sheet, A4, A3 or as per customer requirements
2). Normal thickness: 0.04,0.05,0.06,0.08,0.10mm
3). Color: transparent with one-side glue coating.
4). Package method: by reel or 500 sheets per bag/4-8 bags per paper carton, or as per customer requirements. All the cartons are firmly piled up and fixed on the solid plywood pallet.
5). Storage condition: Sealed, moisture-proof, room temperature under 40℃, Keep it horizontally, avoid heavy pressing and direct sunlight.
| Item | Unit | Value | ||
| Density | g/cm3 | 1.26 ±0.04 | ||
| Tensile Strength | Horizontal | MPa | ≥35 | |
| Vertical | ≥40 | |||
| Vicat 5kg | ℃ | 72±2 |
||
PVC Coated Overlay - Form and Shape
A.Detailed Product Description
1).Thickness Range: 0.04-0.10MM
2).Finish: Matt
3).Size: Customized Roll size or Sheet size
4).High initial stick
B.Manufacture Method
1). Put printing core and two overlay together, then put into the laminator, the temperature is determined as per the instruction of the machine , Pls be noticed that all glue sides of both pvc sheets and overlay are put inward.
2). The lamination usually lasts 10-15minutes ,The pressure is 6-8Mpa, The temperature is 120-140°C
3). Cut the card
3. Application of 40 Mpa PVC Overlay Sheet Strong Adhesion Level PVC Coated Film For PVC Card Sheets Laminating
PVC Strong Coated Overlay Film with Strong initial viscous force , slow decline , yellowing resistance , deformating resistance after laminating.
The surface is smooth , and easy to use. Mainly used for protective film of bank card , social security card , IC card , RF card and other card with higher requirements.
| Product model | Product name | Thickness Range mm | Color | Vicat ℃ | dynes/cm | Apparent density g/cm3 | Peel strength N/cm | Main application |
| PVC coated overlay |
General coated overlay
|
0.04~0.10 | Transparent | 72-76 | 34~44 | 1.12~1.30 | / | It is mainly used for various magnetic stripe cards, phone cards, membership cards and other PVC cards, adhesive force is more than 3.5N. . |
4.Packing of 40 Mpa PVC Overlay Sheet Strong Adhesion Level PVC Coated Film For PVC Card Sheets Laminating
By reel or 500 sheets per bag / 4-8 bags per paper carton , as per customer requirements . All the cartons are firmly piled up and fixed on the solid plywood pallet
