Heavy Matte Laminated Steel Plates Two Sides Covered With Protection Foils
Product Details:
Place of Origin: | China |
Brand Name: | MK |
Model Number: | MSP-M |
Payment & Shipping Terms:
Minimum Order Quantity: | 100 pcs |
---|---|
Price: | USD 6-17 per sheet or negotiable |
Packaging Details: | plywood box with soft protection material inside |
Delivery Time: | 10-20working days |
Payment Terms: | L/C, T/T, Western Union, MoneyGram, D/P, , D/P |
Supply Ability: | 30 thousand pieces per month |
Detail Information |
|||
Material: | Matte Stainless Steel Plates | Surface Finish: | Heavy Matte Finish On Both Sides |
---|---|---|---|
Thickness: | 0.6mm Or 0.8mm | ||
High Light: | stainless steel laminate sheets,steel laminate sheets |
Product Description
Heavy Matte Finish Lamination Steel Plate MSP-M for plastic card laminator use
Heavy Matte Finish Lamination Steel Plate MSP-M for plastic card laminator use have heavy matte finish surfaces (Ra=1.3-1.5) on both sides and are designed for laminating plastic card sheets in the cad laminator. It can ensure perfect plastic card surface finish after lamination.
Key Features:
1. The two sides are covered with protection foils (blue thin films) to ensure good protection on both surfaces. There is no glue left after the foil is removed before the plate is used at the first time.
2. There are no scratches, dents, stripes shadows and dust on plate surfaces.
3. The edges are smooth and deburred with the round curved corners.
Technical Parameters:
Plate size(L×W): A4, A3 or custom-made size
Plate thickness: 0.6mm, 0.8mm (Thickness tolerance: ±0.05mm)
Dimension tolerance: ±1mm for length and width.
Surface roughness: Heavy matte finish (Ra range 1.3-1.5μm)
Thermal transmission: 0.04cal/℃.cm.sec at 20℃
Packaging box: solid plywood carton with soft cushion protection inside.
surface roughtness Ra value | 1.3-1.5μm |
Thickness range | 600 or 800 micron |
Dimension tolerance | ±1mm |
Edge state | smooth and deburred with the round curved corners |
