Product Details:

Place of Origin: China
Brand Name: MK
Model Number: MSP-G

Payment & Shipping Terms:

Minimum Order Quantity: 100 pcs
Price: USD +-15 per sheet or negotiable
Packaging Details: plywood box with soft protection material inside
Delivery Time: 10-20 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram,, D/A, D/P
Supply Ability: 40 thousand pieces per month
Get Best Price Contact Now

Detail Information

Thickness: 0.8 Mm Plate Flatness Level: Maximum 1 Mm/m
Surface Pattern: Heavy Grained Material: Allumium
Roughness: 3.0-6.0um
High Light:

stainless steel laminate sheets

,

steel laminate sheets

Product Description

Heavy Grained laminated allumium plates MSP-G( Roughness:3.0-6.0 um) for cards lamination



Grained laminated allumium plates MSP-G have  grained finish surfaces on both sides and are designed for laminating plastic card sheets . It can ensure perfect plastic card surface finish after lamination.   Our plates are being widely used by many card factories in both China and foreign countries worldwide.

Key Features:



1. The two sides are covered with protection foils (blue thin films) to ensure good protection on both surfaces. There is no glue left after the foil is removed before the plate is used at the first time.

2. Two sides have the grained pattern in the same quality.

3. There are no scratches, dents, stripes shadows and dust on plate surfaces.

4. The edges are smooth and deburred with the round curved corners.

5. After lamination, the plates are not sticking to the laminated plastic sheets.

Galvanized steel Heavy Grained Laminated Allumium Steel Plates For Cards Lamination 0

Technical Parameters:

Material Allumium
Plate size(L×W) A4, A3 or custom-made size
Plate thickness

0.8mm (Thickness tolerance: ±0.05mm)

Dimension tolerance ±1mm for length and width.
Plate flatness level: maximum 1 mm/m
Surface pattern

grained      Roughness:3.0-6.0um

Surface hardness HRC80±20
Thermal transmission 0.04cal/℃.cm.sec at 20℃
Packaging box solid plywood carton with soft cushion protection inside.
Edge state smooth and deburred with the round curved corners
