Customized Size Smart Card Material Silicon Rubber Cushion White Laminated Pad
Product Details:
| Place of Origin: | China |
| Brand Name: | MK |
| Model Number: | MRP-1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 Pieces |
|---|---|
| Price: | Negotiable |
| Packaging Details: | In standard export carton , Strong plywood package with proper soft protection material inside, suitable for long distance for sea or air transport |
| Delivery Time: | 5-15 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram, D/A, D/P |
| Supply Ability: | 10000 Square Meters per Month |
|
Detail Information |
|||
| Sheet Size: | A4, A3 Or Other Customer Requirement | Rigidity: | 55±5 |
|---|---|---|---|
| Breaking Extensibility: | 350 % | Heat-resistant: | 200 ℃ |
| Middle Material: | Black Silica Gel | Facing Material: | High-temperature Endurable Felt |
| High Light: | white polycarbonate sheet,id card material |
||
Product Description
Silicon Rubber Cushion White Laminated Pad Smart Card Material For Plastic Card Laminating Process
Production Specification
| 1. Silicon Rubber Cushion White Laminated Pad Introduction |
Silicon Rubber Cushion White Laminated Pad is designed for the lamination process for various plastic cards including bank card , credit card , and royalty card . It works with lamination steel plate in the plastic card lamination process .
The structure of white silicon cushion pads is white heatproof silicon rubber layers on the surfaces with glass filer in the middle .
Silicon Rubber Cushion White Laminated Pad is suitable for manufacturing kinds of ISO standard cards, ID cards and smart cards. Raw materials are all for anti-high temperature and anti-high pressure. Meeting the requirements of laminating process, as the professional card consumables, they have been widely using for improving the production efficiency and saving energy because of the feature of thermal conductive fast and uniform. Have excellent bibulous performance, can effectively eliminate the risks of bubbles and watermarks on card surface, greatly improved the qualification rate of products, and with good cushioning properties, they can avoid the scratches linked to the hard touching between the heating plate and the trays, benefited to the long using life of above both.
| 2. Silicon Rubber Cushion White Laminated Pad Specification |
Key Features:
1. It is heatproof with great durability, which can well meet the technological requirements in plastic card lamination .
2. It can transfer heat quickly and evenly , which can improve production efficiency and energy conservation .
3. It has good performance of high temperature resistance and excellent elastic resilience .
4. It has good cushioning performance to avoid the damage and scratching resulting from direct contacting between laminator template and lamination steel plates , which can extend the service life of both lamination steel plates and template .
Detailed Product Description
(1) Silicon rubber cushion
(2) High tensile strength and tearing strength,
(3) Long service life,
(4) Heat resistant up to 250
(5) Product Application: It is used for hot-press , widely used for card laminating or furniture , wooden doors of the pressure paste .
(6) Product specification: 1) thickness: 1.5- 3.5mm 2) maximum width: 3800mm with no joint 3) any length 4) color: white
Product Parameter :
1. Heatproof performance: 200℃
2. Tensile strength: 80 N/mm
3. Adhesion: 80 N/mm
4. Hardness SHORE A: 55±5
5. Thickness: 3mm
6. Length and width: A4, A3 or custom-made size (size tolerance: ±1mm)
| Facing material | High-temperature endurable felt |
| Middle material | Black silica gel |
| Rigidity | 50±5 |
| Tensile strength(N/mm) | 60 |
| Adhesion N/mm | 2.5-4.5 |
| Heat-resistant t (℃) | 200 |
| Breaking strength | 80MPa |
| Surface Finish | Woolen |
The technical index:
| Model number | MRP-1 |
| Thickness | 1.5- 3.5mm (Thickness tolerance: ±0.05mm) |
| Length and width | in sheet, A3, A4 or custom-made size |
| Breaking strength | 80 Mpa |
| Hardness SHORE A | 55±5 |
| Adhesive force N/mm | 2.5 -4.5 |
| Breaking extensibility | 350 % |
| Packaging box |
Strong plywood package with proper soft protection material inside, in standard export carton |
| 3. Application of Silicon Rubber Cushion White Laminated Pad |
| 4. Packing of Silicon Rubber Cushion White Laminated Pad |
