Anti Scratch A4 Matte Finish Lamination Plate

Anti Scratch A4 Matte Finish Lamination Plate

Product Details:

Place of Origin: China
Brand Name: MK
Model Number: MSP-M

Payment & Shipping Terms:

Minimum Order Quantity: 100-200 Sheets
Packaging Details: Export standard package with strong plywood box with soft protection material inside
Delivery Time: 10-15 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 40 thousand sheets per month
Get Best Price Contact Now

Detail Information

Apperance: Matte Finish On Both Sides Normal Thickness: Usually 0.6mm Or 0.8mm
Plate Flatness Level: Maximum 1 Mm Sheet Size: A4, A3 Or Customized
Surface Hardness: HRC80±20 Port: Shenzhen Port Or Other
High Light:

Matte Finish Lamination Plate

,

A4 Lamination Plate

,

Anti Scratch Lamination Plate

Product Description

Anti-scratch A4 Matte Finish Laminated Steel Plate For PVC Prelam Lamination

1. Anti-scratch A4 Matte Finish Laminated Steel Plate For PVC Prelam Lamination- Introduction



Slight Matte Finish Lamination Steel Plate MSP-M have matte finish surfaces on both sides and are designed for laminating plastic card sheets in the cad laminator. It can ensure perfect plastic card surface finish after lamination.

Key Features:

1). The two sides are covered with protection foils (blue thin films) to ensure good protection on both surfaces. There is no glue left after the foil is removed before the plate is used at the first time.

2). There are no scratches, dents, stripes shadows and dust on plate surfaces.

3). The edges are smooth and deburred with the round curved corners.

4). Two sides are made matte in the same quality.

5). After lamination, the plates are not sticking to the laminated plastic sheets.

Plate size(L×W): A4, A3 or custom-made size

Plate thickness: 0.6mm, 0.8mm (Thickness tolerance: ±0.05mm)

Dimension tolerance: ±1mm for length and width.

Plate flatness level: maximum 1 mm

Surface roughness value range: 0.3-1.5um

Slight Matte plate (Ra0.3μm-0.5um)

Heavy Matte plate (Ra1.3-1.5um)

Glossy plate surface glossiness: over 800 GU at 20° (both sides)

Surface hardness: HRC80±20

Thermal transmission: 0.04cal/℃.cm.sec at 20℃

Packaging box: solid plywood carton with soft cushion protection inside.

Anti Scratch A4 Matte Finish Lamination Plate 0



2. Anti-scratch A4 Matte Finish Laminated Steel Plate For PVC Prelam Lamination- Parameters

Technical Parameters:



Plate size(L×W) A4, A3 or custom-made size
Plate thicknes 0.6mm, 0.8mm (Thickness tolerance: ±0.05mm)
Dimension tolerance ±1mm for length and width.
Surface roughness Slight matte finish (Ra range 0.3-0.5μm)
Thermal transmission 0.04cal/.cm.sec at 20
Packaging box solid plywood carton with soft cushion protection inside



surface roughtness Ra value 0.3-0.5μm
Thickness range 600 or 800 micron
Dimension tolerance ±1mm for length and width
Edge state smooth and deburred with the round curved corners



3. Anti-scratch A4 Matte Finish Laminated Steel Plate For PVC Prelam Lamination- Application

Detailed Product Description:

1). Glossy finish, matte finish, mirror finish,etc.
2). Size & thickness on request
3). High-grade stainless stee

Features:

1). Card laminator Accessories

2). 800 Micron thickness

3). Characteristic: heat-resistant, high elasticity

Anti Scratch A4 Matte Finish Lamination Plate 1

Anti Scratch A4 Matte Finish Lamination Plate 2

There are five kinds of steel plates:

1).Glossy steel plates

normal mirror effect,for planographic code and inkjet code.

2).Matte steel plates

on te surface there are tiny lights,thin and lubricious,for planographic code and inkjet code.

3).Coarse matte steel

Platoon lights on the surface,too coarse for planographic code.

4).Moderate coarse matte steel plates

no lights on the surface,moderate coarse.

5).Fine matte steel plates

no lights on the surface, relatively thin and lubricious, for paleographic code and

inkjet code.



Size:100mm*120mm;210mm*297mm;210mm*320mm;325mm*480mm;340mm*500mm

Thickness:0.5mm, 0.6mm,0.7mm, 0.8mm, 1mm



4. Anti-scratch A4 Matte Finish Laminated Steel Plate For PVC Prelam Lamination- Packing



Packing:Wood Tree Texture Double Side Laminating Steel Plate for Card Making / Stainless Steel Plate Press on Cards in standard export wooden case

Anti Scratch A4 Matte Finish Lamination Plate 3

Anti Scratch A4 Matte Finish Lamination Plate 4
