ID Card Production Anti Static A3 0.10mm Clear PETG Sheet

ID Card Production Anti Static A3 0.10mm Clear PETG Sheet

Product Details:

Place of Origin: China
Brand Name: MKarte
Model Number: MCS-PETG

Payment & Shipping Terms:

Minimum Order Quantity: 30000 sheets or 2 tons
Price: Negotiable
Packaging Details: 50 or 100 or 200 sheets per bag, 10 bags per paper carton, and the cartons are piled up and firmly fixed on solid plywood pallets
Delivery Time: 10-15 working days
Payment Terms: T/T, L/C, D/A, Western Union, MoneyGram
Supply Ability: 50000 Sheets per Week
Get Best Price Contact Now

Detail Information

Sheet Size: A4, A3 Or Custom-made Specific Gravity: About 1.30 ±0.05
Peel Strength (90°, 300mm/min): ≥6.0 N/cm Aging Time (65℃ Temp./95% Humidity ): >200 Hours
Port: Shanghai Or Other Chinese Port Suitable Ink: Offset And Silk Screen Printing UV Ink, Pigment And Dye Ink For Inkjet Printing As Well As Digital Printing Ink
High Light:

Anti Static Clear PETG Sheet

,

0.10mm Clear PETG Sheet

,

A3 Clear PETG Sheet

Product Description

0.10mm PETG Plastic Sheet Anti Static Impact Resistance For ID Card Production Material



1. Introduction of 0.10mm PETG Plastic Sheet Anti Static Impact Resistance For ID Card Production Material



0.10mm PETG Plastic Sheet Anti Static Impact Resistance is widely used in card base production. It has such features as impact resistance, high temperature resistance, anti-static, abrasion, folding and high strength. It is widely used for the production of high-end credit cards, ID cards and passport, etc.

PETG is a kind of transparent amorphous copolyester.

The performance of PETG is quite different from PET and PC. PETG plate has outstanding toughness and high impact strength, its impact strength is 3-10 times more than ordinary plastic plate, and it has a wide processing range, high mechanical strength and excellent flexibility. Compared with PVC, it has high transparency, good luster and easy to print. At the same time, PETG has environmental protection advaes, and it can be recycled without polluting the environment. PETG sheet has low flammability, good fire resistance, no combustion support, low smoke emission, no harmful substances after combustion.

Card-making method:

1). Print the patterns directly to the material

2). Laminate with overlay

3). Punching

4). Other art-work

ID Card Production Anti Static A3 0.10mm Clear PETG Sheet 0


2.Specification of 0.10mm PETG Plastic Sheet Anti Static Impact Resistance For ID Card Production Material
0.10mm PETG Plastic Sheet Anti Static Impact Resistance is used for national ID cards and other high grade cards.It is capable of achieving laser ablation, sunken cord, leveling up, printed layer,and has resistance to high temperature, high strength and environmental protection.
Technical Parameters:

Item Parameters
Vicat softening point (B50)    78±2
Vicat softening point (A120)   80±2
Heating Shrinkage ratio 105 ℃/10min    ≥-8.0 % (longitudinal) &≥-4.0 %(transverse)
Surface Dyne (dynes/cm) ≥38
Normal thickness in mm 0.10-0.76
Density (g/cm3) 1.30 ±0.05
Peel Strength (90°, 300mm/min) ≥6.0 N/cm
Aging time (65℃ temp./95% humidity ) >200 hours
 Suitable ink offset and silk screen printing UV ink, Pigment and dye ink for inkjet printing as well as digital printing ink

Features:
1).Excellent strength and wear-resisting
2).High temperature and low temperate resistance;
3).Perfect application for laser Engraving
4).Environment-friendly material
5).Longer service life

Item PETG Core Sheet
Color White
Thickness Range(mm) 0.1-0.76
Vicat point ℃ 78-80 ± 2
Tensile strength ≥50 Mpa
Surface Both sides matt
Density 1.3 ± 0.05
Transparency ≤5
Heat shrink ≥-8.0 % (longitudinal) &≥-4.0 %(transverse)


 ID Card Production Anti Static A3 0.10mm Clear PETG Sheet 1
3. Application of 0.10mm PETG Plastic Sheet Anti Static Impact Resistance For ID Card Production Material



Product model Product name Thickness Range mm Color Vicat dynes/cm Apparent density g/cm3 Peel strength N/cm Main application
PETG PETG plastic sheet 0.1-0.76

White


78-80 ≥38 1.3+/-0.05 / It is used for national ID cards and other high grade cards.It is capable of achieving laser ablation, sunken cord, leveling up, printed layer,and has resistance to high temperature, high strength and environmental protection.

Detailed Product Description

1.Thickness:0.1mm to 0.76mm
2.Color: White or customized
3.Surface tension: ≥38 dynes/cm
Characteristic

1.Good lamination properties

2.Good impact resistance

3.Good chemical resistance

4.Excellent printability with either offset or screen printing

5.Laminating Temp 120 degrees Celcius-130 degrees Celcius (lab conditions)

ID Card Production Anti Static A3 0.10mm Clear PETG Sheet 2
 ID Card Production Anti Static A3 0.10mm Clear PETG Sheet 3
4.Packing of 0.10mm PETG Plastic Sheet Anti Static Impact Resistance For ID Card Production Material



In standard export carton: 50 or 100 or 200 sheets per bag, 10 bags per paper carton, and the cartons are piled up and firmly fixed on solid plywood pallets

ID Card Production Anti Static A3 0.10mm Clear PETG Sheet 4
