Product Details:

Place of Origin: China
Brand Name: MK
Model Number: MCS-SIM

Payment & Shipping Terms:

Minimum Order Quantity: 20000 sheets or 2 tons
Price: Negotiable
Packaging Details: 100 or 200 sheets per PE bag, all the bags are firmly piled up and fixed on the solid plywood pallets
Delivery Time: 10-15 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10-15 million square meters per month
Get Best Price Contact Now

Detail Information

Thickness Tolerance: +/-5% Density: 1.42±0.05g/cm3
Vicat 5kg: 80±2℃ Surface Dyne: ≥34dynes/cm
Surface Roughness: 0.7~1.8Ra Printing Method: Offset Printing
High Light:

0.33mm pvc core sheet

,

Offset Printable pvc core sheet

,

1.8Ra pvc core sheet

Product Description

0.33mm Customized Size Offset Printable PVC White Core Sheet



1. Specification of 0.33mm Customized Size Offset Printable PVC White Core Sheet

Offset printing sheets MOP series are designed for offset printer and silk screen printer use. They can also be used as non-printed middle core sheet. They are massively used by many card factories worldwide.
1) Suitable for the whole series of offset printer and silk screen printer.
2) High definition images.
3) Excellent ink adhesion with strong peeling strength after lamination.

4) No crack occurs on the printed images after lamination at high temperature.

Technical parameters:

Item Index
Tensile strength Longitudinal MPa ≥45
Transverse MPa ≥40
Vicat ℃ 77±2
Surface Tension dyne/cm ≥35
Heat shrinkage rate% 140℃ 10min Transverse ≤5
Longitudinal ≥-10
Squareness mm ±1
Thickness tolerance % ±5
Roughness μm Ra,μm 0.7~1.4
Rz,μm 4~9

0.33mm Offset Printable 1.8Ra Pvc Core Sheet 0



2. Parameters of 0.33mm Customized Size Offset Printable PVC White Core Sheet

Thickness Range: 120 ~ 760 Micron
Color: White, Transparent or Colored
Size: Sheet size or roll size

Roughness: Both sides matte

Vicat point: 77+2 ℃ (ISO306B50)

Width: <=1530mm
Inner Core Diameter: 3’’(76mm)

Item Unit Value
Density g/cm3 1.42±0.05



Tensile Strength

Horizontal



MPa

≥44
Vertical ≥46
Vicat 5kg 80±2



Surface Roughness

Ra



μm

0.7~1.8
Rz 4.0~12.0
Surface Dyne dynes/cm ≥34

0.33mm Offset Printable 1.8Ra Pvc Core Sheet 1

*Customized design is availalbe.



3. Packing of 0.33mm Customized Size Offset Printable PVC White Core Sheet

Package method: 100-200 sheets per PE bag, all the bags are firmly piled up and fixed on the solid plywood pallets.

Storage condition: Sealed, moisture-proof, room temperature under 40℃

0.33mm Offset Printable 1.8Ra Pvc Core Sheet 2
