0.1mm A4 Size Transparent PVC Coated Overlay
Product Details:
| Place of Origin: | China |
| Brand Name: | MK |
| Model Number: | MCO-G1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 30000 sheets or 2 tons |
|---|---|
| Price: | Negotiable |
| Packaging Details: | by reel or 500 sheets per bag / 4-8 bags per paper carton , as per customer requirements . All the cartons are firmly piled up and fixed on the solid plywood pallet |
| Delivery Time: | 10-15 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 4 million tons per month |
|
Detail Information |
|||
| Heat Laminating: | 110~130℃ | Normal Thickness: | 0.04，0.05，0.06，0.08，0.10mm |
|---|---|---|---|
| Sheet Surface: | Clean And Flatness | Packing: | PE Film+ Paper Carton |
| Using Method : | Laminate With Inkjet Printed Sheet Directly | Characteristics : | Suitable For Lamination With Inkjet Printer Ink, With Excellent Peel Strength. |
| High Light: | transparent pvc coated overlay,0.1mm pvc coated overlay,a4 pvc coated overlay |
||
Product Description
0.1mm A4 Size Transparent PVC Coated Overlay Laminated With Inkjet and Digital Printing Sheet
| 1. Product Features for 0.1mm A4 Size Transparent PVC Coated Overlay Laminated With Inkjet and Digital Printing Sheet |
It is developed specially for Inkjet printer Ink. It’s suitable for laminating with the sheets which printed by whole series of Inkjet presses. It provides excellent peel strength and no deformation or color change after lamination.
Using Method
Laminate with Inkjet printed sheet directly.
Characteristics
● Suitable for lamination with Inkjet printer Ink, with excellent peel strength.
● Abrasion resistant , prolong the life of cards.
● Environment friendly in the card making process, no solvent or gas discharges.
Laminating Parameters:
| Laminating Unit | Temp(℃) | Pressure(MPa) | Time (min) |
| Heat Laminating | 110~130 | ≥8 | 20 |
| Cool Laminating | ≤20 | ≥8 | 20 |
| 2.Technical Data for 0.1mm A4 Size Transparent PVC Coated Overlay Laminated With Inkjet and Digital Printing Sheet |
Parameters:
1. Size: in reel or sheet, A4, A3 or as per customer requirements
2. Normal thickness: 0.04,0.05,0.06,0.08,0.10mm
3. Color: transparent with one-side glue coating.
4. Package method: by reel or 500 sheets per bag/4-8 bags per paper carton, or as per customer requirements. All the cartons are firmly piled up and fixed on the solid plywood pallet.
5. Storage condition: Sealed, moisture-proof, room temperature under 40℃, Keep it horizontally, avoid heavy pressing and direct sunlight.
| Item | Parameters | |
| Surface | Clean and flatness | |
| Dimensional Tolerance (mm) | ±1 | |
| Angle Cut Tolerance (mm) | ±1 | |
| Diagonal Difference (mm) | ≤1 | |
| Thickness Tolerance (mm) | ±10% | |
| Vicat (℃) | 72±2 | |
| Shrinkage | MD | ≥ - 40% |
| TD | ≤15% | |
| Tensile Strength (MPa) | MD | ≥35 |
| TD | ≥35 | |
| 3. Product Storage for 0.1mm A4 Size Transparent PVC Coated Overlay Laminated With Inkjet and Digital Printing Sheet |
Keep package sealed and moisture-proof, room temperature between 5~30℃.
Keep horizontally, avoid oppress heavily and direct sun light.
Stacking height should not exceed one meter.
Shelf life: One year.
