Digital Print Hp Indigo A4 Pvc Sheet Single Sided For Smart Card Production
Product Details:
Place of Origin: | China |
Brand Name: | MK |
Certification: | ISO |
Model Number: | MDP-HP-SS-W |
Payment & Shipping Terms:
Minimum Order Quantity: | 30000 sheets or 2 tons |
---|---|
Price: | USD0.1-0.3/sheet |
Packaging Details: | export stardard package |
Delivery Time: | 15-20days |
Payment Terms: | T/T, L/C, Western Union, MoneyGram |
Supply Ability: | 30 TONS PER MONTH |
Detail Information |
|||
Size: | A4, A3 Or As Per Customer Requirements (tolerance +/-0.5mm) | Thickness: | 0.15mm-0.40mm (tolerance +/-5%) |
---|---|---|---|
Coating Description: | Digital Ink Coating On One Side And Lamination Glue Coating On Another Side | Color: | Common White/supper White |
Package Method: | 50/100/200 Sheets Per Bag, 10 Bags Per Paper Carton, And The Cartons Are Piled Up And Firmly Fixed On Solid Plywood Pallets | Storage Condition: | Sealed, Moisture-proof, Room Temperature Under 40℃ |
Application: | For Pvc Smart Card Production | Market: | Worldwide With Good Quality And Service |
High Light: | single sided a4 pvc sheet,smart card production a4 pvc sheet,digital print a4 pvc card sheet |
Product Description
Digital print pvc sheet HP Indigo single-sided for smart card production
1. Digital print pvc sheet HP Indigo single-sided for smart card production- Introduction
It is suitable for the whole series of HP Indigo printers. It could be printed directly by digital printers with high definition and real color images.
● specially designed for the whole series of HP Indigo printers. suitable for 4-color model printer such as S2000, S5600, S7600, etc.
● It has superior aging resistance performance comparing with other similar products. After 240h’s aging test (75℃, 95%RH), the peel strength is no less than 4.5N/cm.
● No crack occurs on the printed images after lamination at high temperature.
2. Digital print pvc sheet HP Indigo single-sided for smart card production- Parameters:
Size | A4, A3 or as per customer requirements (tolerance +/-0.5mm) |
Thickness | 0.15mm-0.40mm (tolerance +/-5%) |
Coating description |
digital ink coating on one side and lamination glue coating on another side. |
Color | Common white/supper white |
Package method | 50/100/200 sheets per bag, 10 bags per paper carton, and the cartons are piled up and firmly fixed on solid plywood pallets |
Storage condition | Sealed, moisture-proof, room temperature under |
3. Digital print pvc sheet HP Indigo single-sided for smart card production- Application
Product Test Report | |||||
Product Name: PVC Digital Printing Sheet | |||||
Inspected Items | Unit | Inspection Standard | Test Result | ||
Appearance | The color is even, No black impurity spots, No obvious scratch |
Meet the requirements | |||
Length | mm | ±1 | OK | ||
Width | mm | ±1 | OK | ||
Thickness | mm | ±10% | OK | ||
Squareness | mm/m | ≤1 | 0.4 | ||
Density | g/cm3 | 1.42±0.05 | 1.41 | ||
Chromatic aberration | ∆E | ≤1.0 | 0.51 | ||
Pulling Strength | MD | MPa | ≥45 | 47 | |
CD | ≥43 | 43.1 | |||
Roughness Ra |
4# | ṷ m | 0.7~1.8 | 1.28 | |
5# | ṷ m | 0.7~1.8 | 0.97 | ||
Roughness Rz |
4# | ṷ m | 4~12 | 7.912 | |
5# | ṷ m | 4~12 | 6.91 | ||
Surface Tension | 4# | Dynes/cm | ≥34 | 34.5 | |
5# | ≥34 | 34 | |||
Heating shrinkage rate | MD | % | ≤-6.0 | -2 | |
CD | ≤+2.2 | 0 | |||
Whiteness | 96.2 | ||||
Transmittance | % | 5.5 | |||
Vicat softening point | ℃ | 78±2 | 78.9 |
4. Digital print pvc sheet HP Indigo single-sided for smart card production- Packing
