Inlay / Offset Printing Pvc Foam Core Board Excellent Ink Adhesion
Product Details:
| Place of Origin: | China |
| Brand Name: | MK |
| Model Number: | MOP-W |
Payment & Shipping Terms:
| Minimum Order Quantity: | 30000 sheets or 2 tons |
|---|---|
| Price: | USD 0.05-0.3 per sheet |
| Packaging Details: | 100-200 sheets per PE bag, all the bags are firmly piled up and fixed on the solid plywood pallets. |
| Delivery Time: | 10-15 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 20 million square meters or 5 million tons per month |
|
Detail Information |
|||
| Material: | Blank PVC Core Sheet For Offset Printer Or Silkscreen Printer | Thickness Range: | 120-760micron |
|---|---|---|---|
| Color: | Milk White (MOP-W-NF Model)/Snow White(MOP-W-F Model) | Suitable Printer Models: | The Whole Series Of Offset Printer And Silk-screen Printers |
| Package Method: | 100-200 Sheets Per PE Bag, All The Bags Are Firmly Piled Up And Fixed On The Solid Plywood Pallets. | Vicat ℃: | 77±2 |
| Longitudinal MPa: | ≥45 | Transverse MPa: | ≥40 |
| High Light: | pvc foam core board,clear pvc sheet |
||
Product Description
PVC Core Sheet ( Inlay / Offset Printing PVC sheet / Silk-screen printing PVC sheet) MOP-W
Offset printing sheets MOP series are designed for offset printer and silk screen printer use. They can also be used as non-printed middle core sheet. They are massively used by many card factories worldwide.
Featuers:
1) Suitable for the whole series of offset printer and silk screen printer.
2) High definition images.
3) Excellent ink adhesion with strong peeling strength after lamination.
4) No crack occurs on the printed images after lamination at high temperature.
Technical parameters:
| Item | Index | |
| Tensile strength | Longitudinal MPa | ≥45 |
| Transverse MPa | ≥40 | |
| Vicat ℃ | 77±2 | |
| Surface Tension dyne/cm | ≥35 | |
| Heat shrinkage rate% 140℃ 10min | Transverse ≤5 | |
| Longitudinal ≥-10 | ||
| Squareness mm | ±1 | |
| Thickness tolerance % | ±5 | |
| Roughness μm | Ra,μm | 0.7~1.4 |
| Rz,μm | 4~9 | |
| Thickness | 0.12-0.76mm |
| Color | Milk White (MOP-W-NF model)/Snow White (MOP-W-F model) |
| Suitable printer models | The whole series of offset printer and silk-screen printers |
| Storage condition | Sealed, moisture-proof, room temperature under 40℃ |
| Package method | 100-200 sheets per PE bag, all the bags are firmly piled up and fixed on the solid plywood pallets. |
