High Impact Water PETG Plastic Coated Film Sheet For PETG Material Cards Making
Product Details:
| Place of Origin: | China |
| Brand Name: | MKarte |
| Model Number: | MCO-PETG |
Payment & Shipping Terms:
| Minimum Order Quantity: | 30000 sheets or 2 tons |
|---|---|
| Price: | Negotiable |
| Packaging Details: | by reel or 500 sheets per bag/4-8 bags per paper carton, or as per customer requirements. All the cartons are firmly piled up and fixed on the solid plywood pallet. |
| Delivery Time: | 10-15 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 3 million tons per month |
|
Detail Information |
|||
| Material: | PETG ( Polyethylene Terephthalate ) | Size: | In Reel Or Sheet, A4, A3 Or As Per Customer Requirements |
|---|---|---|---|
| Thickness: | 0.04-0.10mm | Color: | Transparent |
| Package Method:: | By Reel Or 500 Sheets Per Bag/4-8 Bags Per Paper Carton, Or As Per Customer Requirements. All The Cartons Are Firmly Piled Up And Fixed On The Solid Plywood Pallet. | Storage Condition:: | Sealed, Moisture-proof, Room Temperature Under 40℃, Keep It Horizontally, Avoid Heavy Pressing And Direct Sunlight. |
| Glue Coating: | One-side Glue Coating. | Vicat Softening Point (A120): | 78±2 |
| High Light: | petg clear plastic sheet,petg sheet 1mm |
||
Product Description
PETG Plastic Coated Film Sheet / Reel for PETG Material Cards Making
1.PETG Plastic Coated Film Sheet / Reel for PETG Material Cards Making - Introduction
The performance of PETG Coated Overlay Sheet / PETG Coatd Film is quite different from PET and PC. PETG plate has outstanding toughness and high impact strength, its impact strength is 3-10 times more than ordinary plastic plate, and it has a wide processing range, high mechanical strength and excellent flexibility. Compared with PVC, it has high transparency, good luster and easy to print. At the same time, PETG has environmental protection advaes, and it can be recycled without polluting the environment. PETG sheet has low flammability, good fire resistance, no combustion support, low smoke emission, no harmful substances after combustion.
2.PETG Plastic Coated Film Sheet / Reel for PETG Material Cards Making - Parameters
PETG overlay film which used for card making and laminating ,glossy and semi-transparency , Anti-static ,abration,folding,high strength .
Technical Parameters:
| Item | Parameters |
| Vicat softening point (B50) | 74±2 |
| Vicat softening point (A120) | 78±2 |
| Heating Shrinkage ratio 105 ℃/10min | ≥-8.0 % (longitudinal) &≥-4.0 %(transverse) |
| Surface Dyne (dynes/cm) | ≥38 |
| Normal thickness in mm | 0.04,0.05,0.06,0.08,0.10 |
| Density (g/cm3) | 1.20 ±0.05 |
| Peel Strength (90°, 300mm/min) | ≥6.0 N/cm |
| Aging time (65℃ temp./95% humidity ) | ＞200 hours |
| Suitable ink | offset and silk screen printing UV ink, Pigment and dye ink for inkjet printing as well as digital printing ink |
Parameters:
1). Size: in reel or sheet, A4, A3 or as per customer requirements
2). Normal thickness: 0.04,0.05,0.06,0.08,0.10mm
3). Color: transparent with one-side glue coating.
4). Package method: by reel or 500 sheets per bag/4-8 bags per paper carton, or as per customer requirements. All the cartons are firmly piled up and fixed on the solid plywood pallet.
5). Storage condition: Sealed, moisture-proof, room temperature under 40℃, Keep it horizontally, avoid heavy pressing and direct sunlight.
3.PETG Plastic Coated Film Sheet / Reel for PETG Material Cards Making - Application
PETG Coated Overlay Sheet ( PETG Coatd Film) for PETG Card body production (Model: MCO-PETG) has such features as impact resistance, high temperature resistance, anti-static, abrasion, folding and high strength. It is widely used for the production of high-end credit cards, ID cards, special packaging and printing industry.
PETG is a kind of transparent amorphous copolyester.
4.PETG Plastic Coated Film Sheet / Reel for PETG Material Cards Making - Packing
Package method: by reel or 500 sheets per bag/4-8 bags per paper carton, or as per customer requirements. All the cartons are firmly piled up and fixed on the solid plywood pallet.
Storage condition: Sealed, moisture-proof, room temperature under 40℃, Keep it horizontally, avoid heavy pressing and direct sunlight.
