Coated Overlay Film 0.04mm 0.05mm Petg Clear Plastic Sheet

Coated Overlay Film 0.04mm 0.05mm Petg Clear Plastic Sheet

Product Details:

Place of Origin: China
Brand Name: MK
Certification: ISO9001
Model Number: MCO-PETG

Payment & Shipping Terms:

Minimum Order Quantity: 30000 sheets or 2 tons
Price: USD 0.5-3 USD/sheet
Packaging Details: By roll or 500 sheets per bag, 4 or 8 bags per paper cartons which are piled up and firmly fixed on solid plywood pallets
Delivery Time: 10-15 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10 million square meters or 3 million tons per month
Get Best Price Contact Now

Detail Information

Vicat Softening Point (B50): 74±2 Vicat Softening Point (A120) : 78±2
Heating Shrinkage Ratio 105 ℃/10min  : ≥-8.0 % (longitudinal) &≥-4.0 %(transverse) Surface Dyne (dynes/cm): ≥38
Color: Transparent With One-side Glue Coating Loading Port: Shanghai Or Shenzhen Or Other Chinese Port
High Light:

Petg coated overlay film Sheet

,

0.05mm petg clear plastic sheet

,

0.04mm petg clear plastic sheet

Product Description

Customized Size PETG Plastic Sheet Coated Overlay Film With High Temperature Resistance

1. Introduction of Customized Size PETG Plastic Sheet Coated Overlay Film With High Temperature Resistance

PETG Coated Overlay ( PETG Coated Film) for PETG Card body production (Model: MCO-PETG) has such features as impact resistance, high temperature resistance, anti-static, abrasion, folding and high strength. It is widely used for the production of high-end credit cards, ID cards, special packaging and printing industry.

PETG is a kind of transparent amorphous co polyester.

The performance of PETG is quite different from PET and PC. PETG plate has outstanding toughness and high impact strength, its impact strength is 3-10 times more than ordinary plastic plate, and it has a wide processing range, high mechanical strength and excellent flexibility. Compared with PVC, it has high transparency, good luster and easy to print. At the same time, PETG has environmental protection advaes, and it can be recycled without polluting the environment. PETG sheet has low flammability, good fire resistance, no combustion support, low smoke emission, no harmful substances after combustion.

Coated Overlay Film 0.04mm 0.05mm Petg Clear Plastic Sheet 0


2. Parameters of Customized Size PETG Plastic Sheet Coated Overlay Film With High Temperature Resistance

Technical Parameters:
Item Parameters
Vicat softening point (B50)    74±2
Vicat softening point (A120)   78±2
Heating Shrinkage ratio 105 ℃/10min    ≥-8.0 % (longitudinal) &≥-4.0 %(transverse)
Surface Dyne (dynes/cm) ≥38
Normal thickness in mm 0.04,0.05,0.06,0.08,0.10
Density (g/cm3) 1.20 ±0.05
Peel Strength (90°, 300mm/min) ≥6.0 N/cm
Aging time (65℃ temp./95% humidity ) >200 hours
 Suitable ink offset and silk screen printing UV ink, Pigment and dye ink for inkjet printing as well as digital printing ink


 Coated Overlay Film 0.04mm 0.05mm Petg Clear Plastic Sheet 1

Laminating Condition:

Suggested Laminating Condition Laminating Unit Heat Laminating Cool Laminating
Temp 110~130°C ≤25°C
Time 25min 15 min
Pressure ≥5Mpa ≥5Mpa


3. Application of Customized Size PETG Plastic Sheet Coated Overlay Film With High Temperature Resistance

It is widely used in such cards as anti-fake IC cards, driving license card, transportation card and passport etc.
Coated Overlay Film 0.04mm 0.05mm Petg Clear Plastic Sheet 2
