0.2mm Transparent PETG Plastic Sheet For ID Card Production
Product Details:
| Place of Origin: | China |
| Brand Name: | MK |
| Certification: | ISO9001 |
| Model Number: | MCO-PETG |
Payment & Shipping Terms:
| Minimum Order Quantity: | 30000 sheets or 2 tons |
|---|---|
| Price: | Negotiable |
| Packaging Details: | By roll or 500 sheets per bag, 4 or 8 bags per paper cartons which are piled up and firmly fixed on solid plywood pallets |
| Delivery Time: | 10-15 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10 million square meters or 3 million tons per month |
|
Detail Information |
|||
| Density: | 1.30 ±0.05 G/cm3 | Sample: | A4 Or Other Size Rigid PETG Sheet With PP Bag In Box |
|---|---|---|---|
| Sheet Packing: | 30kg Per Bag Or As Your Requirement | Container Loading: | 20 Tons As Normal |
| Pallets Packin: | 500- 2000kg Per Plywood Pallet | Loading Port: | Shanghai Or Other Chinese Port |
| High Light: | 0.2mm PETG Plastic Sheet,ID Card PETG Plastic Sheet,transparent petg plastic sheet |
||
Product Description
0.2mm Transparent Polyethylene Terephthalate Petg Plastic Sheet For ID Card Production
1.Introduction of 0.2mm Transparent Polyethylene Terephthalate Petg Plastic Sheet For ID Card Production
PETG (Polyethylene Terephthalate) card core sheet is widely used in card base production. It has such features as impact resistance, high temperature resistance, anti-static, abrasion, folding and high strength. It is widely used for the production of high-end credit cards, ID cards and passport, etc.
PETG is a kind of transparent amorphous co polyester.
The performance of PETG is quite different from PET and PC. PETG sheet has outstanding toughness and high impact strength, its impact strength is 3-10 times more than ordinary plastic plate, and it has a wide processing range, high mechanical strength and excellent flexibility. Compared with PVC, it has high transparency, good luster and easy to print. At the same time, PETG has environmental protection advaes, and it can be recycled without polluting the environment. PETG sheet has low flammability, good fire resistance, no combustion support, low smoke emission, no harmful substances after combustion.
Technical Parameters:
| Item | Parameters |
| Vicat softening point (B50) | 78±2 |
| Vicat softening point (A120) | 80±2 |
| Heating Shrinkage ratio 105 ℃/10min | ≥-8.0 % (longitudinal) &≥-4.0 %(transverse) |
| Surface Dyne (dynes/cm) | ≥38 |
| Normal thickness in mm | 0.10-0.76 |
| Density (g/cm3) | 1.30 ±0.05 |
| Peel Strength (90°, 300mm/min) | ≥6.0 N/cm |
| Aging time (65℃ temp./95% humidity ) | ＞200 hours |
| Suitable ink | offset and silk screen printing UV ink, Pigment and dye ink for inkjet printing as well as digital printing ink |
2.Features of 0.2mm Transparent Polyethylene Terephthalate Petg Plastic Sheet For ID Card Production
Features
1.High chemical stability, fine anti-fire, super-transparent.
2.Highly UV .stabilized, good mechanical properties, high hardness and strength.
3.The sheet also has well aging resistance, good self-extinguishing property and reliable insularity.
4.Moreover the sheet is waterproof and has very good smooth surface, and is non deformable.
5.Application:chemical industry, oil industry, galvanization, water purification equipments, environment protection equipments, medical appliance and so on.
6.important item: the sheet anti-stastic , anti-UV, anti-sticky
| Product model | Product name | Thickness Range mm | Color | Vicat ℃ | dynes/cm | Apparent density g/cm3 | Peel strength N/cm | Main application |
| PETG | PETG core | 0.1-0.76 |
White
|
78-80 | ≥38 | 1.3+/-0.05 | / | It is used for national ID cards and other high grade cards.It is capable of achieving laser ablation, sunken cord, leveling up, printed layer,and has resistance to high temperature, high strength and environmental protection. |
3.Technical Data Sheet of 0.2mm Transparent Polyethylene Terephthalate Petg Plastic Sheet For ID Card Production
| APPLICATION: |
This PETG WHITE CORE:MCS-PETG is suitable for the production of all type of high grade cards, such us EMV Bank Cards, ID Cards, IC Contact cards, etc. This material has an excellent stability and provides to the card body a very resistant and durable structure. This PETG can be easily implemented by any card manufaturers since it shows the same workability as standard PVC Core. |
||||||||
| APPEARANCE: | WHITE, | MATT/FINE VELVET. | |||||||
| THICKNESS ( mm ) | 100–400 | mm | |||||||
|
THICKNESS TOLERANCE ON 100% OF READINGS |
Between100–200 | mm | ± 7% | ||||||
| Between210–300 | mm | ± 6% | |||||||
| Between 310-400 | mm | ± 5% | |||||||
| PROPERTIES | TEST METHOD | RESPONSE VALUE | |||||||
| VICAT SOFTENING POINT | UNI EN ISO 306 VSTB50 | 76±2°C | |||||||
| (1Kg Load in oil as stacked samples) | |||||||||
| DENSITY | ISO 1183-1 | 1.23 ± 0.04 g/cm3 | |||||||
| SURFACE TENSION | ISO8296 | Best Printing side ³ 39mN/m | |||||||
| Reverse side ³ 36 mN/m | |||||||||
| SURFACE ROUGHNESS | MKarte Test | Ra ( mm ) | Between 0.8~2mm | ||||||
| Rz ( mm ) | - | ||||||||
| GLOSSINESS DEGREE in % | MKarte Test | Thickness £ 300mm | - | ||||||
| Thickness ³ 310mm | - | ||||||||
| TENSILE STRENGTH | UNI EN ISO 527-3/2/50 | CD MPa ³ | - | ||||||
| MD Mpa ³ | - | ||||||||
| MKarte Test | Thickness100-200mm | MD³ -18½CD£ +8 % | |||||||
| HEAT SHRINKAGE in % | |||||||||
| MKarte Test | Thickness210-300mm | MD³ -10½CD£ +5 % | |||||||
| (105±2 °C for 5 Minutes) | |||||||||
| MKarte Test | Thickness310-400mm | MD³ -8 ½CD£ +4 % | |||||||
| TENSILE IMPACT STRENGTH | ISO 8256 | ³ 500 HJ/m2 | |||||||
