A3 Size Silk Screen Printing Pvc Core Sheet Wth Excellent Ink Adhesion

A3 Size Silk Screen Printing Pvc Core Sheet Wth Excellent Ink Adhesion

Product Details:

Place of Origin: China
Brand Name: MK
Model Number: MOP-W

Payment & Shipping Terms:

Minimum Order Quantity: 30000 sheets or 2 tons
Price: Negotiable
Packaging Details: 50 or 100 or 200 sheets per bag, 10 bags per paper carton, and the cartons are piled up and firmly fixed on solid plywood pallets
Delivery Time: 10-15 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10 million square meters per month
Get Best Price Contact Now

Detail Information

Shape: By Sheet Or By Roll Vicat: 77±2℃
Feature: High Definition Images Squareness: ±1mm
Color: Common White/ Super White Application: Suitable For The Whole Series Of Silk Screen Printer.
High Light:

card production pvc core sheet

,

pvc core sheet a3

,

silk screen print pvc core sheet

Product Description

A3 Size Silk Screen Printing PVC Core Sheet Wth Excellent Ink Adhesion



1.Introduction of A3 Size Silk Screen Printing PVC Core Sheet Wth Excellent Ink Adhesion

Silk Screen(Offset printing) sheets MOP series are designed for silk screen (offset printer) printer use. They can also be used as non-printed middle core sheet. They are massively used by many card factories worldwide.
1) Suitable for the whole series of offset printer and silk screen printer.
2) High definition images.
3) Excellent ink adhesion with strong peeling strength after lamination.

4) No crack occurs on the printed images after lamination at high temperature.

Item Unit Value
Density g/cm3 1.42±0.05



Tensile Strength

Horizontal



MPa

≥44
Vertical ≥46
Vicat 5kg 80±2



Surface Roughness

Ra



μm

0.7~1.8
Rz 4.0~12.0
Surface Dyne dynes/cm ≥34

A3 Size Silk Screen Printing Pvc Core Sheet Wth Excellent Ink Adhesion 0



2.Characters of A3 Size Silk Screen Printing PVC Core Sheet Wth Excellent Ink Adhesion

Product Advae:

1. Smooth and Uniform Surface

It is waterproof and has very good smooth surface, and is non-deformable.

2. Reliable Electrical Insulation

It is widely used for different electrical equipment.

3. Excellent Chemical and Corrosion Resistance

It can withstand the erosion of a variety of chemicals.

4. Good Impact Resistance

It has good impact resistance, pressure-resisting and durability.

5. Easily Formed

It is easily formed due to good plasticity, which is suitable for die cutting, vacuum forming and folding.

6. Wide Usage

Size in sheet A4,A3 or custom-made ( ( tolerance +/-0.5mm )
Thickness 0.12-0.76mm (tolerance +/-5%)
Color Milk White (MOP-W-NF model)/Snow White (MOP-W-F model)
Coating description digital ink coating on one side and lamination glue coating on another side.
Package method 100-200 sheets per PE bag, all the bags are firmly piled up and fixed on the solid plywood pallets.
Storage condition Sealed, moisture-proof, room temperature under 40℃ , Keep it horizontally, avoid heavy pressing and direct sunlight

A3 Size Silk Screen Printing Pvc Core Sheet Wth Excellent Ink Adhesion 1



3. Application of A3 Size Silk Screen Printing PVC Core Sheet Wth Excellent Ink Adhesion

This kind of PVC sheet can be used for laminating, non-laminating, printing, coating and

cutting, such as membership cards and calendars

A3 Size Silk Screen Printing Pvc Core Sheet Wth Excellent Ink Adhesion 2

Packing Details
Common package: PE bag+ Kraft paper/PE wrapping + PP belt+Wooden Pallet
Packaging size: 3'x6'(915x1830) /4'x8'(1220x2440) pallet or any customized size wooden pallet.
Delivery time: 10 Days after the receipt of 50% deposit.
Payment: 50% deposit and 50% T/T before shipment.



A3 Size Silk Screen Printing Pvc Core Sheet Wth Excellent Ink Adhesion 3
