0.08mm Eco Friendly Petg Plastic Sheet For Driving Licence Cards Production
Product Details:
| Place of Origin: | China |
| Brand Name: | MKarte |
| Model Number: | MCO-PETG |
Payment & Shipping Terms:
| Minimum Order Quantity: | 30000 sheets or 2 tons |
|---|---|
| Price: | Negotiable |
| Packaging Details: | by reel or 500 sheets per bag/4-8 bags per paper carton, or as per customer requirements. All the cartons are firmly piled up and fixed on the solid plywood pallet. |
| Delivery Time: | 10-15 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 3 million tons per month |
|
Detail Information |
|||
| Material: | PETG ( Polyethylene Terephthalate ) | Size: | In Reel Or Sheet, A4, A3 Or As Per Customer Requirements |
|---|---|---|---|
| Thickness: | 0.04-0.10mm | Surface Dyne (dynes/cm): | ≥38 |
| Glue Coating: | One-side Glue Coating. | PETG Usage: | For Production Of High-end Credit Cards, ID Cards, Special Packaging And Printing Industry. |
| High Light: | 0.08mm petg plastic sheet,eco friendly petg plastic sheet |
||
Product Description
0.08mm Eco Friendly Petg Plastic Sheet For Driving licence Cards Production
1.0.08mm Eco Friendly Petg Plastic Sheet For Driving licence Cards Production - Introduction
The performance of PETG Coated Film, Polyethylene Terephthalate overlay is quite different from PET and PC. PETG plate has outstanding toughness and high impact strength, its impact strength is 3-10 times more than ordinary plastic plate, and it has a wide processing range, high mechanical strength and excellent flexibility. Compared with PVC, it has high transparency, good luster and easy to print. At the same time, PETG has environmental protection advaes, and it can be recycled without polluting the environment. PETG sheet has low flammability, good fire resistance, no combustion support, low smoke emission, no harmful substances after combustion.
PETG Coated Film, Polyethylene Terephthalate overlay is a new developed environment friendly product which could get excellent peel strength at low laminating temperature. It provides superior aging resistance performance to other similar products and no deformation and color change after lamination.
Characteristics:
● Suitable for conventional ink and UV ink, with excellent peel strength.
● Work well at low laminating temperature.
● Could be used for laminating pure PETG card (both overlay and sheet are PETG).
● PETG is one kind of industrial raw material which is certificated by International Union for Conservation of Nature and Natural Resources.
● PETG card is degradable and finally discharge water and carbon dioxide.
2. 0.08mm Eco Friendly Petg Plastic Sheet For Driving licence Cards Production - Parameters
PETG overlay film which used for card making and laminating ,glossy and semi-transparency , Anti-static ,abration,folding,high strength .
Technical Parameters:
| Item | Parameters |
| Vicat softening point (B50) | 74±2 |
| Vicat softening point (A120) | 78±2 |
| Heating Shrinkage ratio 105 ℃/10min | ≥-8.0 % (longitudinal) &≥-4.0 %(transverse) |
| Surface Dyne (dynes/cm) | ≥38 |
| Normal thickness in mm | 0.04,0.05,0.06,0.08,0.10 |
| Density (g/cm3) | 1.20 ±0.05 |
| Peel Strength (90°, 300mm/min) | ≥6.0 N/cm |
| Aging time (65℃ temp./95% humidity ) | ＞200 hours |
| Suitable ink | offset and silk screen printing UV ink, Pigment and dye ink for inkjet printing as well as digital printing ink |
Parameters:
1). Size: in reel or sheet, A4, A3 or as per customer requirements
2). Normal thickness: 0.04,0.05,0.06,0.08,0.10mm
3). Color: transparent with one-side glue coating.
4). Package method: by reel or 500 sheets per bag/4-8 bags per paper carton, or as per customer requirements. All the cartons are firmly piled up and fixed on the solid plywood pallet.
5). Storage condition: Sealed, moisture-proof, room temperature under 40℃, Keep it horizontally, avoid heavy pressing and direct sunlight.
3. 0.08mm Eco Friendly Petg Plastic Sheet For Driving licence Cards Production - Application
PETG Coated Film, Polyethylene Terephthalate overlay for PETG Card body production (Model: MCO-PETG) has such features as impact resistance, high temperature resistance, anti-static, abrasion, folding and high strength. It is widely used for the production of high-end credit cards, ID cards, special packaging and printing industry.
PETG is a kind of transparent amorphous copolyester.
Laminating Condition of PETG Cards:
| Laminating Unit | Temp(℃) | Pressure(MPa) | Time (min) |
| Heat Laminating | 110~130 | ≥6 | 25 |
| Cool Laminating | ≤25 | ≥6 | 15 |
| Item | Parameters | |
| Vicat (℃) | 74 to78±3 | |
| Shrinkage | ≥-8.0 % (longitudinal) &≥-4.0 %(transverse) | |
| Peel Strength (90°, 300mm/min) | ≥6.0 N/cm | |
| Roughness(μm) | Ra | 0.58~2.1 |
| Rz | 3.45 | |
| Thickness(mm) | 0.04,0.05,0.06,0.08,0.10 | |
