Offset Printable Clear Polycarbonate PC Plastic Core Sheet For Contactless IC Cards

Offset Printable Clear Polycarbonate PC Plastic Core Sheet For Contactless IC Cards

Product Details:

Place of Origin: China
Brand Name: MK
Model Number: MCS-PC-INLAY

Payment & Shipping Terms:

Minimum Order Quantity: 30000 sheets or 2 tons
Price: Negotiable
Packaging Details: In standard export carton , 100 or 200 sheets per bag, 10 bags per paper carton, and the cartons are piled up and firmly fixed on solid plywood pallets
Delivery Time: 10-20 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100000 Sheets per Week
Get Best Price Contact Now

Detail Information

Feature: Low Vicat Tensile Strength: ≥50MPa
Glue Coated: Without Coating On Both Sides Density Range: 1.30 ±0.05 G/cm3
Normal Thickness: 0.05-1.0mm Color: Transparent
Appearance: Two Sides Matt Of The PC Sheet Surface Dyne: ≥ 38 Dynes/cm
High Light:

offset printable pc plastic sheet

,

offset printable clear polycarbonate pc sheet

,

contactless ic cards pc plastic sheet

Product Description

Transparent PC Plastic Core Sheet With Low Vicat For Contactless IC Cards Or INLAY Sheet Production



Production Specification

1. Transparent PC Plastic Core Sheet With Low Vicat For Contactless IC Cards Or INLAY Sheet Production Introduction

Transparent PC Plastic Core Sheet With Low Vicat For Contactless IC Cards Or INLAY Sheet Production  (Model: MCS-PC-INLAY) is specially designed for INLAY sheet production of Contactless or RFID PC Card. It is featuring lower vicat softening point, which can provide good protection on chips inside during the process of laminator grading lamination process. It is known as the high-quality PC sheet for various contactless or RFID PC cards.

Transparent PC Plastic Core Sheet With Low Vicat For Contactless IC Cards Or INLAY Sheet Production is specially designed for high end PC card body production. Comparing with other types of plastic core sheets for card body production, it excels in outstanding optical clarity, printability, impact strength and dimensional stability. It is widely used in such cards as anti-fake IC cards, driving license card, transportation card and passport etc.



2. Transparent PC Plastic Core Sheet With Low Vicat For Contactless IC Cards Or INLAY Sheet Production Specification

Transparent PC Plastic Core Sheet With Low Vicat For Contactless IC Cards Or INLAY Sheet Production is known as the new reliable material for PC card body production. It has such features as high vicat point and can be used for laser engraving. The PC sheet is perfect for making ID card, E-Passport etc.

Features as below:
1. Excellent strength and wear-resisting
2. High temperature and low temperate resistance;
3. Perfect application for laser Engraving
4. Non-toxic, environment-friendly material

5. Vivid color and high resolution photo quality.
6. Longer service life

Item Unit Value
Density g/cm3 1.30 ±0.05
Tensile Strength Horizontal MPa ≥50
Vertical ≥50
Vicat 85-90
Surface Dyne dynes/cm ≥38
Thickness range mm 0.05-1.0mm

Offset Printable Clear Polycarbonate PC Plastic Core Sheet For Contactless IC Cards 0
Product details :

Transparent PC Plastic Core Sheet With Low Vicat For Contactless IC Cards Or INLAY Sheet Production which is for PC card production , this material has under mentioned advaes :

1. Excellent strength and wear-resisting.
2. High temperature and low temperate resistance.
3. Perfect application for laser engraving.
4. Environment-friendly material.
5. Longer service life.
6. Perfect image of laser etching technology support, apply to identity cards with anti-fake requirements.

Parameters :

1. Size: 210*297mm ( A4 ) , 310*480mm ( A3 ) or as per customer requirements

2. Thickness: 0.10mm to 0.80mm

3. Color : Transparent

4. Package method : 100 or 200 sheets per bag, 10 bags per paper carton, and the cartons are piled up and firmly fixed on solid plywood pallets

5. Storage condition : Sealed, moisture-proof, room temperature under 40℃

Product name Transparent PC Plastic Core Sheet With Low Vicat For Contactless IC Cards Or INLAY Sheet Production
Color Transparent
Thickness Range 0.05-1.0 mm
Vicat point ℃ 145±2
Tensile strength ≥50 Mpa
Surface Matte on two sides of the PC sheet
Density 1.3 ±0.05 g/cm3
Transparency ≤5
Heat shrink ≤0.5
Surface roughness <1.5
Surface tension dynes/cm ≥38
Glue coated With no coating on both sides
Storage  Sealed, moisture-proof, room temperature under 40℃



3. Application of Transparent PC Plastic Core Sheet With Low Vicat For Contactless IC Cards Or INLAY Sheet Production

It is widely used in such cards as anti-fake IC cards, driving license card, transportation card and passport etc.

Offset Printable Clear Polycarbonate PC Plastic Core Sheet For Contactless IC Cards 1

4. Packing of Transparent PC Plastic Core Sheet With Low Vicat For Contactless IC Cards Or INLAY Sheet Production

In standard export carton and are packed on plywood pallet

Offset Printable Clear Polycarbonate PC Plastic Core Sheet For Contactless IC Cards 2
