Transparent Anti-Aging Polycarbonate PC Card Base Film For Contactless Card
Product Details:
| Place of Origin: | China |
| Brand Name: | MKarte |
| Model Number: | MCS-PC-INLAY |
Payment & Shipping Terms:
| Minimum Order Quantity: | 30000 sheets or 2 tons |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 50 or 100 or 200 sheets per bag, 10 bags per paper carton, and the cartons are piled up and firmly fixed on solid plywood pallets |
| Delivery Time: | 10-15 work days |
| Payment Terms: | T/T, L/C, D/A, Western Union, MoneyGram |
| Supply Ability: | 50000 Sheets per Week |
|
Detail Information |
|||
| Size: | A4.A3.or According To Customs' Request | Tensile Strength-Horizontal: | ≥50 MPA |
|---|---|---|---|
| Vicat: | 85-90 | Tensile Strength-Vertical: | ≥50 MPA |
| Thickness Range: | 0.05-1.0mm | Surface Dyne: | ≥38 Dynes/cm |
| High Light: | clear polycarbonate sheet,polycarbonate transparent sheet |
||
Product Description
PC Plastic core sheet / Polycarbonate PC card base for Contactless Card or RFID INLAY Sheeet production
1.PC Plastic core sheet / Polycarbonate card base - Introduction
PC Plastic core sheet / Polycarbonate card base(Model: MCS-PC-INLAY) is specially designed for INLAY sheet production of Contactless or RFID PC Card. It is featuring lower vicat softening point, which can provide good protection on chips inside during the process of laminator grading lamination process. It is known as the high-quality PC sheet for various contactless or RFID PC cards.
Comparing with other types of plastic core sheets for card body production, it excels in outstanding optical clarity, printability, impact strength and dimensional stability. It is widely used in such cards as anti-fake IC cards, driving license card, transportation card and passport etc.
Features:
1).Excellent strength and wear-resisting
2).High temperature and low temperate resistance;
3).Perfect application for laser Engraving
4).Environment-friendly material
5).Longer service life
2.PC Plastic core sheet / Polycarbonate card base - Parameters
PC Plastic core sheet / Polycarbonate card base is used for national ID cards and other high grade cards.It is capable of achieving laser ablation, sunken cord, leveling up, printed layer,and has resistance to high temperature, high strength and environmental protection.
| Item | PC Core Sheet |
| Color | White, Transparent or Black |
| Thickness Range(mm) | 0.05-1.0 |
| Vicat point ℃ | 85-90 |
| Tensile strength | ≥50 Mpa |
| Surface | Both sides matt |
| Density | 1.3 |
| Transparency | ≤5 |
| Heat shrink | ≤0.5 |
| Surface roughness | ＜1.5 |
| Surface tension dynes/cm | ≥38 |
PC core sheet / Polycarbonate card base with excellent strength and wear resistance, high temperature resistance, perfect image of laser etching technology support.Apply to identity cards with anti-fake requirements, driving license, passport etc.
|
Item |
Unit |
Value |
|
|
Density |
g/cm3 |
1.30 ±0.05 |
|
|
Tensile Strength |
Horizontal |
MPa |
≥50 |
|
Vertical |
≥50 |
||
|
Vicat |
℃ |
85-90 |
|
|
Surface Dyne |
dynes/cm |
≥38 |
|
|
Thickness range |
mm |
0.05-1.0mm |
|
3.PC Plastic core sheet / Polycarbonate card base - Application
PC Plastic core sheet / Polycarbonate card base (Model MCS-PC-INLAY) is specially designed for high end PC card body production.
Comparing with other types of plastic core sheets for card body production, it excels in outstanding optical clarity, printability, impact strength and dimensional stability. It is widely used in such cards as anti-fake IC cards, driving license card, transportation card and passport etc.
PC Plastic core sheet / Polycarbonate card base is known as the new reliable material for PC card body production. It has such features as high vicat point and can be used for laser engraving. The PC sheet is perfect for making ID card, E-Passport etc.
Card-making method
1). Print the patterns directly to the material
2). Laminate with overlay
3). Punching
4). Other art-work
| Product model | Product name | Thickness Range mm | Color | Vicat ℃ | dynes/cm | Apparent density g/cm3 | Peel strength N/cm | Main application |
| PC | PC core | 0.05- |
White Black Transparent |
85-90 | ≥38 | 1.3+/-0.05 | / | It is used for national ID cards and other high grade cards.It is capable of achieving laser ablation, sunken cord, leveling up, printed layer,and has resistance to high temperature, high strength and environmental protection. |
4.PC Plastic core sheet / Polycarbonate card base - Packing
