Product Details:

Place of Origin: China
Brand Name: MK
Certification: ISO9001
Model Number: MCS-PC-L

Payment & Shipping Terms:

Minimum Order Quantity: 30000 sheets or 2 tons
Price: Negotiable
Packaging Details: 50 or 100 or 200 sheets per bag, 10 bags per paper carton,and all cartons are piled up and firmly fixed on solid plywood pallets
Delivery Time: 10-15 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 150000 Sheets per Week
Get Best Price Contact Now

Detail Information

Product Name: Laserable Polycarbonate Overlay Normal Thickness In Mm: 0.04,0.05,0.06,0.08,0.10
Sheet Surface: Matt/Matt, Flat, No Defect, No Dust Coating Availability: No Coatings On Both Sides
Usage: Apply To Identity Cards With Anti-fake Requirements Packing: Paper Carton + Plywood Pallet
High Light:

Laserable polycarbonate overlay

,

0.10mm polycarbonate overlay

,

0.80mm polycarbonate overlay

Product Description

Laserable Polycarbonate Overlay Transparent 0.10mm 0.80mm PC Plastic Sheet


1. Product Introduction of Laserable Polycarbonate Overlay Transparent 0.10mm 0.80mm PC Plastic Sheet
 Polycarbonate overlay is specially designed for laser engraving feature on card surface. After lamination, it can leave clear and neat laser marks on card surface. Comparing with other types of plastic films for card body production, it excels in outstanding optical clarity, printability, impact strength and dimensional stability.


ItemUnitValue
Densityg/cm31.30 ±0.05
Tensile StrengthHorizontalMPa≥50
Vertical≥50
Vicat145±2
Surface Dynedynes/cm≥38

Laserable Transparent 0.10mm 0.80mm Polycarbonate Overlay 0

2. Product Features of Laserable Polycarbonate Overlay Transparent 0.10mm 0.80mm PC Plastic Sheet

Parameters:
1. Size: in sheet or reel, A4, A3 or as per customer requirements
2. Normal thickness in mm: 0.04,0.05,0.06,0.08,0.10
3. Color: transparent without coating on surface.
4. Package method: in reel or 500 sheets per bag/4 bags per paper carton, or as per customer requirements.
5. Storage condition: Sealed, moisture-proof, room temperature under 40℃, Keep it horizontally, avoid heavy pressing and direct sunlight.
6. Perfect image of laser etching technology support, apply to identity cards with anti-fake requirements.

Technical parameters
ItemStandard Value

Thickness

(mm)

0.04-0.085 ( ±5%)
SurfaceMatt/Matt, flat, no defect, no dust.
Tensile Strength (Mpa) -ISO527-3≧50(MD/CD)
Break Strength (%) -ISO527-3≧60(MD/CD)

Folding Capacity


Thickness <0.25mm, ≧13
Thickness ≧0.25mm,≧11
Light Transmittance (%)≧80
Haze (%)≦ 90
Surface Tension(Dynes/cm) -ISO 8296-2003≧34

Heating Shrinkage (%)

(135℃±2,10min)

Thickness≤ 0.175mmMD≦2.5
CD≦0.5
Vicat Softening Temperature(℃) - ISO 306-1994150±3
Coating availabilityNo coatings on both sides

Laserable Transparent 0.10mm 0.80mm Polycarbonate Overlay 1

3. Testing report of Laserable Polycarbonate Overlay Transparent 0.10mm 0.80mm PC Plastic Sheet

FeatureTesting methodUnitTesting value
Physics
Specific gravityASTM D792G/cm³1.2
Average water absorptionASTM D570%0.35
Mechanical
Tensile strengthASTM D882Psi8800
ISO R1184-1987Mpa60
Ultimate elongationASTM D882%>90
Impact strengthJIS-k6745In-ibs120
Tear strengthASTM D1922G/mil>30
Temperature resistance
Vicat softening pointASTM D1525128
Thermal shrinkageD1204%<1.0
Electrical
Dielectric strengthASTM D149V/mil1700
Volume InsulationASTM D257Ohm.mLaserable Transparent 0.10mm 0.80mm Polycarbonate Overlay 2
Surface InsulationASTM D257OhmLaserable Transparent 0.10mm 0.80mm Polycarbonate Overlay 3
Roughness value
Medium sand umRa3.45
Fine sand umRal.5~2.1
Matte umRa0.58
Featureunitlimit
Thickness tolerance%>0.5±0.006mm
≤0.5 ±0.004mm


Laserable Transparent 0.10mm 0.80mm Polycarbonate Overlay 4
