Laminating Magnetic Stripe Coated Overlay For Plastic Card Lamination

Laminating Magnetic Stripe Coated Overlay For Plastic Card Lamination

Product Details:

Place of Origin: China
Brand Name: MKarte
Model Number: MCO-MS

Payment & Shipping Terms:

Minimum Order Quantity: 20000-30000 Sheets
Price: Negotiable
Packaging Details: By standard export carton and packed in strong plywood pallet with proper soft protection material inside, suitable for long distance for sea or air transport
Delivery Time: 10- 25 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram, D/A, D/P
Supply Ability: 50 tons per Month
Get Best Price Contact Now

Detail Information

Color: Transparent With One-side Glue Coating Laminating Temperature: 110-150℃
Storage Condition: Sealed, Moisture-proof, Room Temperature Under 40℃, Keep It Horizontally, Avoid Heavy Pressing And Direct Sunlight Size Tolerance: +/-0.5 Mm In Length And Width, +/-5% In Thickness
Magnetic Stripe Feature:: HICO/LOCO, Standard Width 12.7mm, Black Color, Peelable Transfer Model, Brand Of Magnetic Stripe: LUCKY
High Light:

abrasion resistant overlay

,

a4 coloured overlays

Product Description

Magnetic Stripe Coated Overlay with Lucky Brand HICO / LOCO For Plastic Card Lamination


Production Specification

1. Magnetic Stripe Coated Overlay with Lucky Brand HICO / LOCO- Introduction



PVC coated overlay with magnetic stripes MCO-MS is applied with standard magnetic stripe. It applies the high-quality magnetic stripe made by LUCKY China. It can be directly laminated with the printing sheets in the card laminator before punched into standard magnetic card. It features high adhesion, no color change and deformation with long aging life after the process of lamination.



Using method: cover the printed plastic sheets and then laminate together.

Technical Notice :

In manufacturing process, it can be directly laminated with PVC printing sheet, which will simplify the fabrication process and save time, and also the product's adhesive strength is high.

Steps to make cards:

1). Put printing core and two overlays together , then put into the laminator . ( the laminating temperature and time is determined as per the instruction of the machine ) . Please be noticed that all glue sides of both PVC sheets and Overlays are put inward .

2). Tlamination lasts 10-15 minutes . The pressure is 6-8Mpa. The temperature is 120-140°C.

3). Cutting the card.

Laminating Magnetic Stripe Coated Overlay For Plastic Card Lamination 0

2. Magnetic Stripe Coated Overlay with Lucky Brand HICO / LOCO- Specification



Detailed Product Description

Coated overlay with magnetic strip hico 2750 oe or loco 360oe , used for card making and laminating ,one side is with magnetic strip,another side for laminating.

1). It has strong adhesive effect

2). it apply to most of the bank card and smart card lamination.
3). Yellow resistance

4). Magnetic strip is not easy to peel off .

Laminating Magnetic Stripe Coated Overlay For Plastic Card Lamination 1

Specifications:

Product name A4 Size Black Magnetic Stripes Coated Overlay Sheet For Plastic Card Lamination
Common size A4, 310x480mm (A3, customized )
Thickness 0.04mm -1.0 mm
Appearance transparent
Coated glue on back
Laminating temperature 110-150℃
Storage -10~35℃, sealed, moisture-proof
Shelf life 2 years
Packing method 100pcs/bag, 4000pcs/carton





3. Magnetic Stripe Coated Overlay with Lucky Brand HICO / LOCO- Product Parameter


1).Size: by reel or by sheet, A4, A3 or as per customer requirements
2). Coated overlay thickness range in mm: 0.04,0.05,0.06,0.08,0.10
3). Magnetic stripe feature: HICO/LOCO, standard width 12.7mm, black color, Peelable transfer model, Brand: LUCKY
4). Size tolerance: +/-0.5 mm in length and width, +/-5% in thickness.
5). Color : transparent with one-side glue coating
6). Length and width: in sheet, 210*297 mm ( A4 ) , 295*480 mm ( A3 ) or custom-made size (size tolerance: ±1mm)

7). Package method: 500 sheets a bag, 50 bags one carton , packed in Pallets

8). Storage condition: Sealed, moisture-proof, room temperature under 40℃, Keep it horizontally, avoid heavy pressing and direct sunlight.

Laminating Magnetic Stripe Coated Overlay For Plastic Card Lamination 2

The technical Parameters:

 Model number  MCO-MS
 Thickness   0.04 mm,0.05mm,0.06mm ,0.08mm ,0.10mm
 Common Size  Sheet size or Roll size, any size as your requirement
 Color  Clear (Transparent)
 Glue Coated  Yes
 Application  Magnetic strip Card Making
 Type  Heat press
 Advae  Waterproof, Moistureproof, Customized layout
Packaging method

 By standard export carton and packed in strong plywood pallet with proper soft   protection material inside, suitable for long distance for sea or air transport



4.Magnetic Stripe Coated Overlay with Lucky Brand HICO / LOCO-  Application

 Magnetic Stripe Coated Overlay with Lucky Brand HICO / LOCO is used as an outer layer on the printed PVC sheets in card lamination. It simplifies the card making process and provides high bonding strength. It efficiently prevents the cards from scratching or cracking , and cuts down the waste rate in production.
In manufacturing process, it can be directly laminated with PVC printing sheet, which will simplify the fabrication process and save time.

Laminating Magnetic Stripe Coated Overlay For Plastic Card Lamination 3







5.Magnetic Stripe Coated Overlay with Lucky Brand HICO / LOCO-  Packing

 Laminating Magnetic Stripe Coated Overlay For Plastic Card Lamination 4
In standard export carton and packed in plywood pallet
