0.04-0.10 Mm Magnetic Stripes Coated Films With High Bonding Strength
Product Details:
| Place of Origin: | China |
| Brand Name: | LUCKY China |
| Model Number: | MCO-MS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 20000-30000 Sheets |
|---|---|
| Price: | Negotiable |
| Packaging Details: | In standard export carton or strong plywood package with proper soft protection material inside, suitable for long distance for sea or air transport |
| Delivery Time: | 10- 20 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram, D/A, D/P |
| Supply Ability: | 5 million square meters per month |
|
Detail Information |
|||
| Common Size: | Sheet Size Or Roll Size , A4 , A3 Or Custom-made Size | Thickness Range: | 0.04-0.10 Mm |
|---|---|---|---|
| Material: | PVC | Package Method: | In Standard Export Carton: 100/200 Sheets Per Bag Or As Per Customer Requirements |
| Classify: | HI_CO 2750OE, LO_CO 300OE | Packaging Details: | 500 Sheets A Bag, 50 Bags One Carton ,packed In Pallets |
| High Light: | clear overlay sheets,a4 coloured overlays |
||
Product Description
Magnetic Stripes Coated Overlay Films For Magnetic Stripe PVC Plastic Card Production
Production Specification
| 1. Magnetic Stripes Coated Overlay Films For Magnetic Stripe PVC Plastic Card Introduction |
Magnetic Stripes Coated Overlay Films For Magnetic Stripe PVC Plastic Card MCO-MS is applied with standard magnetic stripe. It applies the high-quality magnetic stripe made by LUCKY China . It can be directly laminated with the printing sheets in the card laminator before punched into standard magnetic card. It features high adhesion , no color change and deformation with long aging life after the process of lamination .
Magnetic Stripes Coated Overlay Films For Magnetic Stripe PVC Plastic Card is used as an outer layer on the printed PVC sheets in card lamination. It simplifies the card making process and provides high bonding strength. It efficiently prevents the cards from scratching or cracking, and cuts down the waste rate in production.
Steps to make cards:
1. Put printing core and two overlays together , then put into the laminator . ( the laminating temperature and time is determined as per the instruction of the machine ) . Please be noticed that all glue sides of both PVC sheets and Overlays are put inward .
2. Tlamination lasts 10-15 minutes . The pressure is 6-8Mpa. The temperature is 120-140°C.
3. Cutting the card.
Technical Note :
In manufacturing process, it can be directly laminated with PVC printing sheet, simplify the fabrication process, save time, adhesive strength is high.
| 2. Magnetic Stripes Coated Overlay Films For Magnetic Stripe PVC Plastic Card Specification |
Product Parameter :
1.Size: in sheet, A4, A3 or as per customer requirements
2. Coated overlay thickness range in mm: 0.04,0.05,0.06,0.08,0.10
3. Magnetic stripe feature: HICO/LOCO, standard width 12.7mm, black color, Peelable transfer model, Brand: LUCKY
4. Size tolerance: +/-0.5 mm in length and width, +/-5% in thickness.
5. Color : transparent with one-side glue coating
6. Length and width: in sheet, 201*297 mm ( A4 ) , 310*480 mm ( A3 ) or custom-made size (size tolerance: ±1mm)
7. Package method: 100/200 sheets per bag or as per customer requirements.
8. Storage condition: Sealed, moisture-proof, room temperature under
Detailed Product Description
Coated overlay with magnetic strip hico 2750 oe or loco 360oe , used for card making and laminating ,one side is with magnetic strip,another side for laminating.
1. It has strong adhesive effect
2. it apply to most of the bank card and smart card lamination.
3. Yellow resistance
4. Magnetic strip is not easy to peel off .
Specifications:
| Lamination Temperature | 120-140 ℃ |
| Thickness of overlay | 0.04~0.1mm |
| Size | Sheet size or Roll size, any size as your requirement |
| Classify | HICO 2750OE, LOCO 360OE |
| Color | Clear (Transparent) |
| Glue Coated | YES |
The technical index:
| Model number | MCO-MS |
| Normal Thickness in mm | 0.04,0.05,0.06,0.08,0.10 |
| Normal Size | Sheet size or Roll size, any size as your requirement |
| Color | Clear (Transparent) |
| Glue Coating | With coating on both sides |
| Material | PVC |
| Application | Magnetic Strips Card Making |
| Type | Hot pressing |
| Advae | IWaterproof, Moistureproof, Customized layout |
| Packaging box |
In standard export carton or strong plywood package with proper soft protection material inside, suitable for long distance for sea or air transport |
| 3. Application of Magnetic Stripes Coated Overlay Films For Magnetic Stripe PVC Plastic Card |
In manufacturing process, it can be directly laminated with PVC printing sheet, which will simplify the fabrication process, save time.
| 4. Packing of Magnetic Stripes Coated Overlay Films For Magnetic Stripe PVC Plastic Card |
In standard export carton and are packed plywood pallet
