0.08mm High Adhesion A4 Size Pvc Magnetic Stripe Coated Overlay
Product Details:
Place of Origin: | China |
Brand Name: | LUCKY China |
Model Number: | MCO-MS |
Payment & Shipping Terms:
Minimum Order Quantity: | 20000-30000 Sheets |
---|---|
Price: | Negotiable |
Packaging Details: | In standard export carton or strong plywood package with proper soft protection material inside, suitable for long distance for sea or air transport |
Delivery Time: | 10- 20 working days |
Payment Terms: | L/C, T/T, Western Union, MoneyGram, D/A, D/P |
Supply Ability: | 5 million square meters per month |
Detail Information |
|||
Common Size: | In In Sheet, A4, A3 Or As Per Customer Requirements | Thickness Range: | 40micron To 100micron |
---|---|---|---|
Color: | Transparent With One-side Glue Coating | Supply Ability: | 30000000 Pieceper Month |
Packaging Information: | Wrapped In PE Bag And Carton Shipped In Wooden Pallet | Loading Port: | Shanghai Or Other Chinese Port |
Highlight: | a4 pvc coated overlay,pvc magnetic stripe coated overlay,a4 magnetic stripe coated overlay |
Product Description
0.08mm High Adhesion A4 Size PVC Coated Overlay with Magnetic Stripes
1.Production Specification of 0.08mm High Adhesion A4 Size PVC Coated Overlay with Magnetic Stripes
Product Description
Coated overlay with magnetic strip hico 2750 oe, used for card making and laminating ,one side is with magnetic strip,another side for laminating.
1.It has strong adhesive effect,
2. it apply to most of the bank card and smart card lamination.
3.Yellow resistance,
4.Magnetic strip is not easy to peel off .
Name | Coated overlay laminating film with magnetic stripe |
Size | 210mm*297mm,297mm*420mm,305mm*460mm,or customized. |
Thickness | 0.04mm-0.1mm |
Lamination temperature | 120℃-140℃ |
Color | black,brown |
Package |
50/100 sheets/bag with caraton shipped in wooden pallet, in sheet or in roll |
Classification | HI-CO 2750 OE ,LO-CO 300 OE |
2.More details of 0.08mm High Adhesion A4 Size PVC Coated Overlay with Magnetic Stripes
Product Parameter :
1.Size: in sheet, A4, A3 or as per customer requirements
2. Coated overlay thickness range in mm: 0.04,0.05,0.06,0.08,0.10
3. Magnetic stripe feature: HICO/LOCO, standard width 12.7mm, black color, Peelable transfer model, Brand: LUCKY
4. Size tolerance: +/-0.5 mm in length and width, +/-5% in thickness.
5. Color : transparent with one-side glue coating
6. Length and width: in sheet, 201*297 mm ( A4 ) , 310*480 mm ( A3 ) or custom-made size (size tolerance: ±1mm)
7. Package method: 100/200 sheets per bag or as per customer requirements.
8. Storage condition: Sealed, moisture-proof, room temperature under 40℃, Keep it horizontally, avoid heavy pressing and direct sunlight.
Size | A4, A3 or as per customer requirements |
Coated overlay thickness range in mm | 0.04,0.05,0.06,0.08,0.10 |
Magnetic stripe feature | HICO/LOCO, standard width 12.7mm, black color, Peelable transfer model, Brand: LUCKY |
Size tolerance | +/-0.5 mm in length and width, +/-5% in thickness. |
Color | transparent with one-side glue coating |
Package method | 100/200 sheets per bag or as per customer requirements |
Storage condition | Sealed, moisture-proof, room temperature under 40℃, Keep it horizontally, avoid heavy pressing and direct sunlight. |
3.Application of 0.08mm High Adhesion A4 Size PVC Coated Overlay with Magnetic Stripes
PVC Coated magnetic stripe overlay film is used as an outer layer on the printed PVC sheets in card lamination. It simplifies the card making process and provides high bonding strength. It efficiently prevents the cards from scratching or cracking, and cuts down the waste rate in production.
